Technical Specification | SUN2000-60KTL-M0 | |||
Efficiency | ||||
Max. efficiency | 98.9% @480 V; 98.7% @380 V / 400 V | |||
European efficiency | 98.7% @480 V; 98.5% @380 V / 400 V | |||
Input | ||||
Max. Input Voltage | 1100V | |||
Max. Current per MPPT | 22A | |||
Max. Short Circuit Current per MPPT | 30A | |||
Start Voltage | 200V | |||
MPPT Operating Voltage Range | 200V~1000V | |||
Rated Input Voltage | 600 V @380 Vac / 400 Vac; 720 V @480 Vac | |||
Number of MPP trackers | 6 | |||
Max. input number per MPP tracker | 2 | |||
Output | ||||
Rated AC Active Power | 60,000 W | |||
Max. AC Apparent Power | 66,000 VA | |||
Max. AC Active Power (cosφ=1) | 66,000 W | |||
Rated Output Voltage | 220 V / 380 V, 230 V / 400 V, default 3W + N + PE; 3W + PE optional in settings; 277 V / 480 V, 3W + PE | |||
Rated AC Grid Frequency | 50 Hz / 60 Hz | |||
Rated Output Current | 91.2 A @380 V, 86.7 A @400 V, 72.2 A @480 V | |||
Max. Output Current | 0.8 leading… 0.8 lagging | |||
Max. Total Harmonic Distortion | ＜3% | |||
Protection | ||||
Input-side Disconnection Device | Yes | |||
Anti-islanding Protection | Yes | |||
AC Overcurrent Protection | Yes | |||
DC Reverse-polarity Protection | Yes | |||
PV-array String Fault Monitoring | Yes | |||
DC Surge Arrester | Type II | |||
AC Surge Arrester | Type II | |||
DC Insulation Resistance Detection | Yes | |||
Residual Current Monitoring Unit | Yes | |||
Communication | ||||
Display | LED indicators; WLAN adaptor + FusionSolar APP | |||
RS485 | Yes | |||
USB | Yes | |||
Monitoring BUS (MBUS) | Yes (isolation transformer required) | |||
Smart Dongle-4G | 4G / 3G / 2G via Smart Dongle – 4G (Optional) | |||
General Data | ||||
Dimensions (W x H x D) | 1,075 x 555 x 300 mm (42.3 x 21.9 x 11.8 inch) | |||
Weight (with mounting plate) | 74 kg (163.1 lb.) | |||
Operating Temperature Range | -25°C ~ 60°C (-13°F ~ 140°F) | |||
Cooling Method | Natural Convection | |||
Max. Operating Altitude | 4,000 m (13,123 ft.) | |||
Relative Humidity | 0 ~ 100% | |||
DC Connector | Amphenol Helios H4 | |||
AC Connector | Waterproof PG Terminal + Terminal Clamp | |||
Protection Degree | IP65 | |||
Topology | Transformerless | |||
Nighttime Power Consumption | < 2 W | |||
Standard Compliance (more available upon request) | ||||
Certificate | EN 62109-1/-2, IEC 62109-1/-2, EN 50530, IEC 62116, IEC 60068, IEC 61683 | |||
Grid Connection Standards | IEC 61727, VDE-AR-N4105, VDE 0126-1-1, BDEW, VDE 4120, UTE C 15-712-1, CEI 0-16, CEI 0-21, RD 661, RD 1699, P.O. 12.3, RD 413, EN-50438-Turkey, EN-50438-Ireland, C10/11 | |||
